CE Max Width 1600mm Steel Slitting Machinery Max Thickness 5mm

ZJ1600 x 5.0mm sitting line specification

I. Equipment specification: ( 0.8-5mm) *1600mm

Il. Process flow:

Loading coil - decoil -Press and lead steel strip - Simply calibrclip steel strip-guide-slit-Collect the edges - Pre-separation - Press the strip- Separate the steelstrip-Coil-Pack

1Il. Main technical parameters:

1. Material of the strip:

Ordinary carbon steel strip: 0.8-5mm

2.Strip thickness: 0.8-5mm

3. Strip width: 1600mm

4. Cutting accuracy: ±0.1mm

5. Cutting speed: 0- 45m/min

6. The load-bearing capacity of the decoiler: 20T

7. Inner diameter of coil: 500mm

8. Outer diameter of coil: 1800mm

9. Motor:

Cutter: 75KW

Coiler: 90KW

10. The power supply: 380V,50Hz,Three-phase electricity

ther Model Of Slitting Line

Model (mm)	Plate thickness (mm)	Plate width (mm)	Steel coil weight (T)	Finished width (mm)	Shear article number	Shear speed(m/min)
3×500	0.4-3	100-500	7	≥30	≤6	140
3×600	0.4-3	100-600	8	≥30	≤6	140
3×800	0.5-3	200-800	10	≥30	≤8	140
3×1250	0.5-3	400-1250	15	≥30	≤10	120
3×1500	0.5-3	600-1500	20	≥30	≤12	120
3×1800	0.5-3	900-1600	30	≥40	≤13	120
4×1600	0.5-4	900-1600	30	≥60	≤13	120
6×1600	1-6	900-1600	30	≥60	≤10	110
8×2000	2-8	900-2000	35	≥70	≤6	100
10×2200	3-10	900-2200	35	≥80	≤5	80
12×2200	3-12	900-2200	35	≥100	≤5	50
16×2500	4-16	900-2500	35	≥100	≤5	40
20×2500	6-20	900-2500	35	≥100	≤4	40
