Fast Speed Steel Pipe Manufacturing Machine With Flexible Strip Width

Ask Lasest Price
Brand Name :	TENG TIAN
Model Number :	CTL-1600×4mm
Certification :	CE / ISO9001
Price :	$100000 to $1 million
Payment Terms :	T/T, L/C
Supply Ability :	20 Sets / Year
Delivery Time :	90 working days

Add to Cart

Product Details
Company Profile

Fast Speed Steel Pipe Manufacturing Machine With Flexible Strip Width

Fast Speed Steel Pipe Manufacturing Machine with flexible Strip Width

Introduction:
This Steel Pipe Manufacturing Machine Fast Speed with flexible Strip Width is able to uncoil & level a coil strip, and then shear the leveled flat strip to certain length of sheets at line speed of max 100m/min. It is referred as Pipe Mill machine in general place.

The Pipe Mill line adopts servo length-fixing and pneumatically mechanical shearing to make sure sheet length precision and clean shearing notch.

The Steel Pipe Manufacturing Machine Fast Speed with flexible Strip Width is composed of: coil loading car, single-mandrel decoiler, coil-head guide, press & shoveling equipment, pinch-feeding roller & leveling machine, hole accumulator, side guide, fine leveling & length-fixing machine, pneumatically mechanical shearing machine, delivery belt, piling-up bracket, up-down lifting table, moving-out car, hydraulic system and electric control system.

Advantages and Characteristics of Pipe Manufacturing Machine Fast Speed with flexible Strip Width:
1. Fast speed and high precision
Line speed can be up to 100m/min, 25-30pcs/min 2000mm Length sheets in average.
Leveling precision: ±1mm/㎡
Sheet length precision: ±0.5mm/m
Sheet diagonal length precision: ±0.5mm/m
2. Thin coils differ in coil weight, when max coil weight is small, usually single mandrel (cantilever) uncoiler for this high-speed cut-to-length line is adopted.
3. To make flat steel sheets, the diameter of leveling rollers should be scientifically proper, we confirm diameter of leveling rollers by actual experiences and engineering calculation.
4. Automatically piling-up bracket can receive finished sheets and automatically pile them up orderly.
5. Hole accumulator between leveling machine and fine leveling, is necessary to protect sheet surface and make sure the simultaneously work of leveling machine DC motor and fine leveling servo motor.

Fast Speed Steel Pipe Manufacturing Machine List

No.	Model	Pipe Size	Thickness	Speed(m/min)	Capacity(KW)	HF(KW)	Area(LxW in Metres)
1	HG20	ø8 - ø20 mm	0.3 - 1.5 mm	30 - 150	210	100	40*12
2	HG32	ø10 - ø32 mm	0.4 - 2.0 mm	30 - 150	300	150	40*12
3	HG50	ø16 - ø50 mm	0.7 -2.5 mm	30 - 150	410	200	60*12
4	HG60	ø22 - ø60 mm	0.9 - 3.0 mm	30 - 150	410	200	60*12
5	HG76	Ø25 - ø76 mm	1 - 4 mm	30 - 120	580	300	80*16
6	HG89	Ø32 - ø89 mm	1 - 4.5 mm	30 - 100	660	300	100*16
7	HG114	Ø45 - ø114 mm	1.5 -5 mm	30 - 80	920	400	100*16
8	HG140	Ø50 - ø140 mm	1.5 - 5.5 mm	30 - 80	920	400	100*16
9	HG165	Ø60 - ø165 mm	2 - 6 mm	30 - 60	1100	500	100*16
10	HG219	Ø114 - ø219mm	3 - 8 mm	20 - 45	1400	600	150*16
11	HG273	Ø114 - ø273mm	4 - 12 mm	15 - 30	2100	800	160*18
12	HG325	Ø165 - ø325 mm	4 - 14 mm	10 - 30	2500	1000	200*24
13	HG426	Ø165 - ø426 mm	4 - 16 mm	8 - 25	2900	1200	250*24
14	HG508	Ø219 - ø508 mm	5 - 18 mm	5 - 18	3400	1600	300*24
15	HG610	Ø355 - ø610 mm	5 - 18 mm	5 - 18	3700	1600	300*24
16	HG760	Ø426 - ø760 mm	5 - 20 mm	5 - 20	4300	1800	300*24
